Self-inspection P10 Outdoor Full color LED Display 7500cd/㎡

Product Categories
Shenzhen Weigu Electronic Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Self-inspection P10 Outdoor Full color LED Display 7500cd/㎡

  • 1
  • 2

Brand Name : Vegoo

Model Number : VG-FD P10

Certification : CE/ROHS/FCC/

Place of Origin : China

Supply Ability : 3000Sq.m

Delivery Time : 3-5 days

Packaging Details : Plywood case / Flight case / Carton box

product name : P10 Outdoor Full color LED Display

Pixel Pitch : 10mm

Density : 10,000 pixel/m2

Moduel Size(L×W)mm : 320mm×160mm or 160mm×160mm

Cabinet Size(L×W×H)mm : 960mm×960mm×130mm

Cabinet Resolution : 96×96

Driving Method : 1/ 4 Scan

Driving IC : MBI5124

Contact Now


Description:


• Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.



• Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.



• Spare parts: necessary spare parts are provided together with products to customers.



• Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.



• Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.



P10 Outdoor Full color LED Display Specification



Product Name Specification
Pixel Pitch 10mm
Pixel Configuration 1R1G1B/DIP 346
Density 10,000 pixel/m2
Moduel Size(L×W)mm 320mm×160mm or 160mm×160mm
Cabinet Size(L×W×H)mm 960mm×960mm×130mm
Module Resolution 32×16
Cabinet Resolution 96×96
Driving Method 1/ 4 Scan
Driving IC MBI5124
Brightness 7500cd/㎡
Contrast 1000:1
Brightness Adjustment Auto and Manual
Module Weight 0.5kg
Color Temperature 9500K—11500K
Horizontal Viewing Angle 140º
Vertical Viewing Angle 140º
Signal Processing 10 or 14bit
Control Distance cable100m,Multimode500m,Single mode 2km
Frame Frequency 65 Hz
Refresh Rate >1920Hz
Control Mode Synchronous/Asynchronous
The Opposite Calibration Curve With Eight Optional Gamma Calibration Curve
Users can choose the recommended curve or adjust it based on actual situation
MTBF >50000 hours
Life Span 100,000 Hours
Operating Temperature Working : -20 - 65 ℃
Storage : -40 - 85 ℃
Environment Temperature -30℃ to 60℃; humidity Rh10% to 95%
Remote Control Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply AC 110-220V
Protection waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)




Self-inspection P10 Outdoor Full color LED Display 7500cd/㎡
